BravoPro HD115 6ch DMX Console

Compact six-channel DMX512 desk with six faders plus a master over one 3-pin XLR universe and no menus to learn. Runs on mains or a 9V battery, and hires across the Gold Coast and Brisbane.

Channels	6 DMX channels + master
Faders	6 channel sliders + master slider
DMX Output	1× 3-pin female XLR (DMX512)
DMX Polarity	Switchable (2−,3+ or 2+,3−)
Power	9–12V DC plug-pack (included) or 9V battery
Dimensions	173 × 153 × 55 mm
Weight	800 g
Compliance	Australian RCM mark

Overview

About the BravoPro HD115

The BravoPro HD115 is a compact six-channel DMX512 controller: six channel faders plus a master, sending one DMX universe over a 3-pin XLR. No pages, no programming, no menus. Push a fader, get light. For jobs where a full console is overkill, it is the fastest way to put manual control of a small rig in anyone’s hands.

Typical applications

Manual control of dimmer packs and relay channels on small conventional rigs
Market stalls, pop-ups and foyer displays needing simple level control
Theatre education and community halls, where an operator-proof first desk earns its keep
Backup and utility desk for testing fixtures and dimmer circuits on site

Built for the field

Switchable DMX polarity drives fixtures wired to either standard, and the desk runs from its included 9-12V DC plug-pack or a 9V battery, which is handy for focus walks and quick fixture checks away from power. At 173 × 153 × 55 mm and 800 g it disappears into any case.

Hire it for your next show

The BravoPro HD115 is part of the Krank’d control inventory, available across the Gold Coast, Brisbane, and Australia-wide. We supply, rig, and operate. Your event, our show.
